Heavy Duty Side Wall Trailer

A Tip trailer, also known as a semi-low bed trailer, is a type of semi-trailer that features a flat loading surface. These trailers are widely used and considered the most common trailers across the country.

At Autocraft Trailer, we ensure that our flatbed trailers meet the same high-quality parameters as our tip trailers. This uncompromising commitment to excellence makes our flatbed trailers unbeatable in the market. We prioritize delivering exceptional quality, durability, and performance in every product we manufacture.

Features

• CHASSIS All steel welded construction. Main longitudinal members: 2 Nos “I” section of material IS 2062 + EBR 350 Equivalent running along the full length of the trailer. Rolled cross members of material IS-2062 are positioned at suitable locations to support the pallets. A 3.15 mm thick chequered sheet shall be provided.
• LANDING LEG One set of two-speed landing legs shall be provided at the front end. Make: YORK OR EQUIVALENT
• KING PIN 2” kingpin equivalent to IS: 6763 Part I provided Make: YORK OR EQUIVALENT.
• SUSPENSION 09 leaf tridem suspension Make: YORK ( YTE 75) / OR EQUIVALENT
• BRAKES Twin line air brake system coupled to tractor brake system. Trailer brakes are actuated by a tractor. The parking brake shall be manually actuated. Brake chamber T30/T24 shall be provided in all axles. LQRV provided for Break efficiency.
• PAINTING Surface Shall be cleaned by shot blasting, 1coat primer and one coat quick dry paint as finish paint.

Details
